The Autumn Red Casing Top Assembly (#9283632) is the correct replacement part for your Miele C3 Softcarpet Vacuum Autumn Red.
Replacement Options for Autumn Red Casing
The C3 Autumn Red casing top assembly is available from several authorized retailers. Note that some suppliers categorize this as a "special order" item.
- Miele Official: Listed as Material #9283632 for the Autumn Red Casing Top.
Key Technical Details
- Universal Components: If the casing top itself is fine but you only need hinges, the hinges are universal and fit all C3 models.
- Installation: Replacing the casing involves accessing the bag and filter compartment and wiggling the lid side-to-side to remove it. Several Torx T20 screws must be removed from the main shell and motor area to fully detach the top.
- Compatibility: Ensure your vacuum's model number on the ID plate matches "Autumn Red" to avoid another color mismatch like the previous "Softcarpet" Tayberry lid incident.
|
9283632
|
C3 Softcarpet Casing top Autumn Red Assembly |
$119.00
|
unit | |||
|
Gross weight per units: 0.587 kilogramme
Packaging size: 425mm x 240mm x 170mm
EAN: 4002516862840
|
||||||
|
10084201
|
C3 Softcarpet Tool Lid Tayberry |
$69.50
|
unit | |||
|
Gross weight per units: 0.287 kilogramme
Packaging size: 295mm x 190mm x 140mm
EAN: 4002515932940
|
||||||
